Bosch Smart Home Floor Heating 230V Thermostat II
14-784261
Main info
The smart flush-mounted control for wired heating systems - ensures optimal comfort temperature through flexible operating options.
You want to make your gas boiler or water-bearing underfloor heating smart? The Room Thermostat II 230 V is the smart solution for all heating systems with wired control.
Make heating boiler & underfloor heating smart
The Room Thermostat II 230 V controls floor heating, gas boiler, radiator thermostats and other wired heating systems smartly and efficiently.
Always read temperature & heating status
The Room Thermostat II 230 V always displays the current room temperature and signals executed actions via a multi-travel LED light strip.
Flexible control of (floor) heating
Underfloor heating control is versatile: from classic on the device to fully automated, via time programs, by voice assistant and of course mobile via app.
Underfloor heating control via voice assistant
hr smart thermostat for underfloor heating and other wired heating systems can also be conveniently controlled by voice: it is compatible with the voice assistants Amazon Alexa and Google Assistant.
Features:
- Make wired heating systems (e.g. water-bearing underfloor heating) smart.
- Always read room temperature and heating status
- Control flexibly (e.g. by voice, time programs, etc.)
- Measure temperature and relative humidity
- Take heating breaks in summer and cool via underfloor heating
- Create time programs
Notes:
- Can only be used in combination with the Bosch Smart Home Controller.
- Installation of this device as well as work on the 230 V mains may only be carried out by a qualified electrician
- Installation: In device boxes with a depth of 35 mm or more and a device screw spacing of 60 mm
Technical data:
- Dimensions (W x H x D): 86 x 87 x 35 mm
- Ambient temperature: 0 - 50 degrees
- Radio frequency: 2.4 - 2.4835 GHz
- Radio range in free field: <100m
- Overload protection: Temperature fuse
- Protection class: IP21
- Max. Humidity: 80% (non-condensing)
- Radio protocol: ZigBee 3.0
- Max. Transmit power: 10 dBm
- Max. Current consumption: 1A
- Cable type and cross section: Rigid and flexible cable 1.0 - 1.5 mm²
- Ohmic load: 3A
- Inductive load: 1A
- Impulse withstand voltage: 3000 V
- Pollution degree: 2
- Mode of operation: Type 1.B
- Temperature of ball pressure test: 125°C
- Construction: Independently mounted, electronic regulation and control unit.
Dimensions and weights
Product codes
