Network Attached Storage - Synology RackStation RS2423RP+ 2U AMD Ryzen V1780B Black, Grey Synology R
158-SYSERRS2426O
Main info
The Synology RackStation RS2423RP+ features an AMD Ryzen V1780B processor with 4 cores and 8 GB DDR4 memory, supporting up to 32 GB. It has a 2U rack design, supports 12 storage drives with RAID options, and includes multiple Ethernet LAN ports for connectivity.Warning: Last items in stock!
The Synology RackStation RS2423RP+ features an AMD Ryzen V1780B processor with 4 cores and 8 GB DDR4 memory, supporting up to 32 GB. It has a 2U rack design, supports 12 storage drives with RAID options, and includes multiple Ethernet LAN ports for connectivity.
- Processor: AMD Ryzen V1780B with 4 cores, 3.35 GHz (boost up to 3.6 GHz)
- Memory: 8 GB DDR4, expandable up to 32 GB with ECC support
- Storage: Supports up to 12 HDD/SSD drives with RAID levels JBOD, 0, 1, 5, 6, 10
- Network: 3 Ethernet LAN ports with speeds up to 10 Gbit/s, iSCSI support, and link aggregation
- Dimensions: 2U rack mount design, weighing 11.9 kg, with active cooling and 3 fans
| Processor | |
|---|---|
| Processor cores | 4 |
| Processor family | AMD Ryzen |
| Processor model | V1780B |
| Number of processors supported | 1 |
| Processor frequency | 3.35 GHz |
| Processor manufacturer | AMD |
| Processor boost frequency | 3.6 GHz |
| Memory | |
| ECC | Yes |
| Internal memory | 8 GB |
| Memory form factor | UDIMM |
| Internal memory type | DDR4 |
| Memory slots | 2 |
| Maximum RAM supported | 32 GB |
| Design | |
| Chassis type | Rack (2U) |
| Product colour | Black, Grey |
| LED indicators | Yes |
| Cooling type | Active |
| Number of fans | 3 |
| Fan diameter | 6 cm |
| Power | |
| AC input frequency | 50 - 60 Hz |
| Redundant power supply (RPS) support | Yes |
| Power consumption (typical) | 114.86 W |
| AC input voltage | 100 - 240 V |
| Power supply unit (PSU) capacity | 350 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Weight & dimensions | |
| Height | 88 mm |
| Weight | 11.9 kg |
| Depth | 578 mm |
| Width | 482 mm |
| Network | |
| Wake-on-LAN ready | Yes |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100, 1000 Mbit/s, 10, 10000 |
| iSCSI support | Yes |
| Ethernet LAN data rate supported (max) | 10000 Mbit/s |
| Link aggregation | Yes |
| Performance | |
| Backup function | Yes |
| Type | NAS |
| On/off switch | Yes |
| Browser supported | Chrome, Firefox, Edge, Safari |
| Security algorithms | AES |
| Noise level | 56.2 dB |
| Snapshot | Yes |
| Built-in FTP server | Yes |
| Multilingual support | Yes |
| Backup features | Cloud, iSCSI LUN |
| System log | Yes |
| Access Control List (ACL) | Yes |
| Device class | Small & Medium Business |
| Management protocols | SNMP |
| Packaging content | |
| Power cables quantity | 2 |
| Cables included | AC |
| Rack mount kit | Yes |
| Software | |
| Operating system installed | DiskStation Manager |
| Operating system version | 7.1.1 |
| Storage | |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | Serial ATA |
| RAID levels | JBOD, 0, 1, 10, 5, 6 |
| Number of storage drives supported | 12 |
| RAID support | Yes |
| Hot-swap drive bays | Yes |
| Storage drive sizes supported | 3.5", 2.5" |
| Supported file systems | exFAT, HFS+, BTRFS, ext3, NTFS, ext4, Fat |
| Online RAID migration | Yes |
| Online RAID expansion | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 3 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| USB port | Yes |
| Other features | |
| Compliance certificates | RoHS, CE |
| Sustainability | |
| Sustainability certificates | CE, RoHS |
| Sustainability compliance | Yes |
| Width | 482 mm |
| Height | 88 mm |
| Length | 578 mm |
| Product Weight | 11900 g |
| Country | TW |
